Tire and Tube Setup: Crucial for Performance

Most of these problems are likely to happen with a gravel race setup using butyl tubes. They are more prone to damage and don't withstand the constant flexing between the road surface and the rim as well. They are also the heaviest choice, which will be explained more in the section on rotating mass below. Are there alternatives to butyl? The tubeless setup works better for gravel racing and serious training. Without a tube, the tire seals directly against the rim thanks to specific technical requirements. A latex-based sealant fluid moves easily inside the tire, sealing small punctures in the casing as the sealant escapes through them. Tubeless systems also perform well at low tire pressure, and without a tube, they are lighter than a butyl tube. The downsides compared to all other options are the high maintenance needs and the mess that can happen from punctures or repairs. That said, when comparing tubeless to the classic butyl tube in gravel racing, the tubeless system comes out on top.

* Energy lost through deformation and internal friction of the tire and tube as they are compressed and flexed between the rim and the road surface.

TPU — The New Competitor in Bicycle Tubes

Newer and more modern than either of these competitors is the innovative TPU tube. Thermoplastic polyurethane — TPU for short — is a plastic material that is highly moldable under heat and has been well researched. Using it for bicycle tubes, however, is relatively new. To give a quick overview: the material is more durable than butyl, while also being lighter, more flexible, and less permeable to air molecules at the same pressure. In the butyl versus TPU matchup, one side clearly has the advantage. That leaves the comparison between a new-generation TPU tube and a tubeless setup. Depending on the amount of sealant added, a TPU tube is barely — if at all — heavier than running without a tube. In terms of puncture resistance, an AERON/TPU model is comparable. Running tubeless does carry a higher risk of perforation since there's no tube to prevent punctures, but a tubeless system can self-seal small holes. Regarding rolling resistance, the TPU tube is slightly behind. First, there's no tube-to-tire friction during flex when running tubeless; second, the sealant — like the TPU tube — adds a small amount of rotating mass. When it comes to efficiency, TPU tubes and tubeless systems are top contenders and perform very closely.

Here's how tubes affect ride characteristics and racing performance:

• The lower weight of TPU tubes decreases the overall bike weight by about 200 grams compared to a setup with butyl tubes. Similar weight savings on a frame or components can cost four figures in the performance market.
• Including potential spare tubes, the weight benefit of TPU tubes can amount to nearly a kilogram.
• TPU folds and bends easily and causes very little surface friction. This results in less energy loss to flex work* when tires and tubes are compressed against the road and deformed under the rider's weight. In simple terms: TPU tubes roll more smoothly than butyl at the same tire pressure.
• The walls of a TPU tube are exceptionally thin, yet they are actually more resistant to punctures. The material is highly stretchable before it tears. Foreign objects are more likely to push a pocket into the material rather than immediately puncturing it, as they would with a butyl tube. The chances of getting a flat rear significantly. A flat tire in a gravel race can set you back considerably, and depending on the timing or frequency, one or more flats can even force you to abandon the race.
• The most measurable difference between butyl and TPU, however, lies in the reduction of "rotating mass." Anyone who has driven a car with an unbalanced wheel knows how it feels. Even a few extra grams in one spot can cause significant vibration during rapid wheel rotation. The farther from the center of rotation and the faster the mass spins around that center, the greater the impact of each gram — even when the rotating mass is fairly evenly distributed, as with a tube. Every gram of tube must be spun up to speed with every acceleration. To illustrate: imagine a tire filled with sand. Spinning that up to 240 RPM — roughly equivalentto 30 mph — would require a huge amount of energy. Switching from butyl to AERON/TPU means roughly 200 fewer grams need to be brought up to speed. But over hours, weeks, and years, that loss accumulates.
• Unproven but logical: the reduced gyroscopic forces in the wheels from the mass savings of TPU tubes should also make it easier to steer and corner. The overall bike should therefore also feel more agile to handle.

*Gyroscopic forces: Basically, these are the combined effects of the rotational inertia of a spinning wheel. Every gram of the wheel's mass tends to keep moving in its original direction of rotation, similar to water droplets flung off as the wheel spins. This is why fast-spinning or heavy wheels are difficult to redirect without significant effort.

You can push the savings to the extreme with real-world numbers. In the example below, a common but heavy butyl tube weighing 209 grams is compared to the AERON/TPU CX/Gravel SuperLite Race AL, which weighs just 33 grams. The energy savings over 50 accelerations to a still-realistic 37 mph amounts to over 50,000 joules. The curve also shows that the savings don't increase linearly with higher top speeds — they scale exponentially.

Underlying sample calculation for energy expenditure (butyl)

In simple terms, this calculation shows that the mass of tires and tubes should be counted as twice their actual weight when calculating energy use because they are concentrated as a ring around the rotation axis. With two AERON/TPU SuperLite Race tubes and two standard-weight butyl tubes (180 g each), this results in a "weight advantage" of nearly 456 grams — almost one pound — during acceleration.

Energy and Savings Opportunities

The table and chart below show the energy savings in joules at different race paces. As you can see, wheel mass does not affect rolling resistance (E_roll). The estimated 3,280 feet (1,000 meters) of climbing makes a noticeable difference — on their own, two lightweight TPU tubes save nearly 2,000 joules during climbs (E_climb) — but this is independent of speed. In a gravel race, braking and accelerating happen frequently, so the calculation includes 50 full stops. The result: in a fast race, a lighter tube saves almost as much energy during stop-and-go riding (E_stop&go) as it does over 3,280 feet of climbing.

This projection is just one example, but two AERON/TPU tubes saving 100 grams each lead to about 16 seconds of time saved over a 62-mile (100 km) gravel race with 3,280 feet of elevation gain compared to heavy butyl tubes — not counting punctures avoided.

Energy Savings Over Distance: Efficiency From 60 to 190 Miles

The Chart shows that energy savings from lightweight TPU tubes increase with distance. This is due not only to weight but also to the fact that the dashed line accounts for an average of one puncture per 62 miles — a realistic figure with butyl tubes. The green line shows savings attributable to weight and rotating mass alone. The blue graph represents a rider who completes a 186-mile (300 km) race without a flat, running two AERON/TPU tubes in the tires and saving an additional 300 grams by carrying TPU spare tubes as well. The blue rider is approximately 9 minutes and 30 seconds faster than the green rider — without pedaling a single additional watt.

"TPU Is Fragile" — Is That True?

Not at all — unless you held a lighter to it. Although the thin wall of a modern TPU tube looks extremely delicate, puncturing or tearing it actually requires much more force than with a butyl tube — by a large margin. Before such a TPU layer tears, it can stretch considerably more than butyl or latex. One exception: when the tube gets very hot, it loses its structural integrity. After all, it is a thermoformable material. But those temperatures are never reached inside a tire, even during extended braking with rim brakes instead of disc brakes. The AERON/TPU models in the City/Tour category withstand these temperatures well enough to be fully approved for use with rim brakes. When it comes to damage like holes, pinch flats, and fatigue from flex work, the plastic is significantly superior to all other tube materials. Even the valves of an AERON/TPU tube — whether plastic or aluminum — are no more fragile than those on butyl alternatives.

"Only for Weight Weenies?"

A weight savings of 200 grams on a total system weight of the bike and rider, which is nearly 175–220 lbs, seems very minimal — and that makes TPU tubes appear as a niche product for that kind of rider. But first, we've already analyzed the potential savings above. And second: the puncture resistance alone and the reliable handling at low tire pressure already elevate TPU bicycle tubes to a different level. The fact that the bike also rolls more easily, accelerates better, and may even handle more nimbly — whether you think that matters or not — means you'll gain benefits from switching either way.

"Tubeless Is Non-Negotiable in Racing!"

In a race, flats are even more damaging and frustrating than during training. So, it makes sense to rely on a system that can repair itself. But: whether the sealant in a tubeless tire effectively seals a puncture airtight depends heavily on the size and type of damage, the amount of latex sealant present, and the remaining pressure in the tire. A TPU tube has two advantages. First, the extra layer inside the tire — which is also highly resistant to punctures due to its stretchability — makes air-losing defects less likely than with the same tire running tubeless. Second, even larger punctures can be repaired relatively quickly in a way that holds air. A TPU tube that's been roughly patched from the inside can survive even in a more severely damaged tire — whereas a tubeless tire with the same damage would require multiple rubber plugs to be inserted and bonded at the puncture site before it could be ridden again.

Where TPU Makes More Strategic Sense

Risk assessment is crucial here. TPU tubes are generally the better choice when you're unsure of what you'll encounter. In terms of rolling resistance and weight, the TPU tube is comparable to tubeless — in some cases slightly behind. When it comes to puncture frequency, it really depends on the terrain. As you'll read below, tubeless tires excel most on very rough, slow trails or on smooth, fast stretches without anything that could damage the tire casing. In between, the TPU tube is the all-around best: it prevents punctures that could sideline a tubeless setup, and if a flat occurs, you're back on the trail quickly. A patched tubeless tire with spentsealant won't be rideable again without extensive maintenance. And if fixing a tubeless failure requires a spare tube anyway, you might as well start with one from the beginning — saving yourself the hassle of carefully cleaning the tire during installation.

When Tubeless Is the Advantage

Technical gravel races often prioritize technical challenges over speed, emphasizing grip and a smooth, responsive feel. In such cases, a tubeless setup can be more efficient. A well-chosen tubeless wheelset allows you to lower tire pressure slightly more, giving the tread a bit more grip. On very rough courses — especially in MTB terrain — an ultra-soft tubeless tire can provide extra comfort. However, this benefit is mainly noticeableat tire pressures around 15 psi.

Long-distance events: Some gravel races cover hundreds of miles on smooth, hard-packed surfaces without heavy impacts or technical sections. In these cases, rolling resistance is the main factor — and in the TPU versus tubeless comparison, both perform well. Smooth surfaces usually pose little risk of serious tire damage, and at most, there may be occasional small punctures, if any. For tiny punctures like these, sealant is very reliable. With a TPU tube, the chances of losing air on such a course are low — but if a small puncture does happen, you'll lose some time repairing it.

Pack Size, Weight, and Quick Roadside Repairs

AERON/TPU tubes weigh up to 78 percent less than a traditional butyl tube in their lightest versions. Even the more puncture-resistant ExtraLite Protect version offers savings of up to 63 percent. In terms of packed volume, three to four AERON/TPU tubes fit in the space of a single butyl tube. Installation is similar to that of a conventional tube with some practice — only inflation requires slightly more care.

Note: Extra steps are necessary when switching from tubeless to TPU. Rims and tires designed for tubeless use must fit more precisely to seal without a tube. This can require a lot of force when mounting or removing the tire. Similar to butyl tubes, there's a risk of damaging the new tube during this process. Whether you're switching to a TPU spare tube after a tubeless failure or permanently returning to a setup with tubes, it's crucial to thoroughly remove all sealant residue. In the short term, TPU and sealant don't react, but over time, the sealant can harden, causing the tube to stick or produce debris that may puncture the thin TPU wall.

TPU vs. Tubeless in Gravel Racing: An Honest Evaluation

The original question was: which wheel setup would you choose if you're racing for the best possible result in a gravel race? And after reviewing all available data, the answer still involves a bit of a gamble. When you strip away the strong ride and damping characteristics shared by both TPU tubes and tubeless systems, what remains is how they each behave in the event of a puncture — or when riding over sharp objects on thecourse.

The chance of the tread, casing, and TPU tube all getting punctured at the same time is lower than the chance of a tubeless tire of the same quality being perforated without a tube. AERON/TPU has shown in lab tests that you're statistically more likely to complete a ride without a defect. But when damage happens, the two systems respond differently. With a tube, you need to replace it; tubeless tires can self-seal small punctures. However, if you hit more than one thorn or nail, tubeless tires are more likely to leave you completely sidelined — unless you insert a spare tube and thoroughly clean the tire first.

Our Take and Pick

For a gravel race through moderate terrain that stays close to civilization, a tubeless setup with a moderate amount of sealant is very sensible. Serious damage is unlikely, and if you can't continue, you'll still make it home safely. The same goes for MTB courses where the tubeless setup's low-pressure benefits are useful.

That said, the frequent switching of setups can be a hassle, and not everyone has a second wheelset — let alone a second gravel bike. For us, the all-around qualities of the TPU tube outweigh the disadvantages. Lab tests at AERON/TPU suggest that punctures are so rare that the time lost — if any — from changing tubes might be minimal. Meanwhile, the tools and spare tubes are small enough that even in the worst case, you'll make it to the finish line.

And that's ultimately what every gravel event is about: finishing.

What advantages do TPU tubes offer for gravel riding? They significantly reduce rotating mass, enhancing acceleration and agility. At the same time, they are more resistant to pinch flats and punctures — perfect for varied terrain and all-around gravel bikes and riders.

How do TPU tubes compare to tubeless? Tubeless remains unbeatable for maximum grip at very low tire pressures on rough terrain. TPU, however, is easier to handle, cleaner to install, and has similarly low rolling resistance. Tubeless is better suited for the most extreme conditions.

Can I use TPU tubes with any gravel tire? Generally, yes, as long as the tire size and valve type match. However, during installation, you should watch for sharp burrs on the rim or damage to the rim tape, as TPU tubes are more sensitive to these.

Can I patch a TPU tube on the road? Yes, with specialized TPU patch kits that include the proper adhesive and cleaner, which create a durable bond when used correctly. Standard bicycle patches don't work here because vulcanizing glue doesn't adhere to TPU.

What advantage does TPU have over tubeless in a race? Installation is quicker, neater, and less prone to errors — a benefit in races where puncture chances and downtime matter most. It also avoids sealant loss and reduces pressure fluctuations during hours of riding.

Is switching from butyl to TPU worth it for gravel racing? For almost every rider, definitely — because TPU tubes reduce system weight and provide a very direct, responsive feel. Anyone seeking maximum performance with low risk and little hassle will find a great alternative to butyl.

Do TPU tubes provide measurable time benefits in gravel racing? Yes, the decreased rotating mass enhances acceleration and responsiveness, especially out of corners or on short, punchy climbs. In races with many turns, this adds up to a noticeable efficiency improvement.

Are TPU tubes dependable enough for long gravel races (60+ miles)? Yes, especially AERON/TPU models, which maintain stable pressure over long distances and experience less thermal expansion than latex, for example. For ultra-gravel events, their lightweight design and puncture resistance are especially appealing, since the longer the course, the higher the chance of a flat that loses pressure — even with tubeless.

Are TPU tubes an advantage in wet or muddy race conditions? Yes, because the precise, "snappy" feel is helpful even on soft terrain. Additionally, the low air permeability of the plastic prevents pressure from dropping noticeably during cold, wet conditions over the course of a race.

Which TPU models are especially suitable for racing? For race use, ultralight, performance-focused TPU tubes with reinforced valve bases are a worthwhile investment. When the size fits well, they offer better efficiency and reliability than any other option. Find our top choice for gravel racing here.

Are there risks in running TPU at its limit? At very low pressures, the chance of pinch flats goes up — at least compared to tubeless. Riders pushing TPU to the edge should keep at least 3–4 psi above their tubeless pressure.
